Silicon Bronze Slotted Flat Head Machine Screw
Silicon Bronze Slotted Flat Head Machine Screws are high-performance fasteners designed for applications requiring a flush surface finish and exceptional corrosion resistance. They are widely used in marine, electrical, construction, and industrial environments where strength, durability, and long service life are essential.
Applications
- Marine and shipbuilding
- Electrical and switchgear equipment
- Architectural hardware
- Telecommunications
- Renewable energy systems
- Industrial machinery
- Automotive and transportation equipment
Features
- Excellent corrosion and saltwater resistance
- Flat head design provides a flush finish after installation
- Precision-machined slotted drive for easy installation
- High tensile strength and durability
- Non-magnetic and electrically conductive
- Resistant to oxidation and harsh weather conditions
- Suitable for indoor and outdoor applications
Specification
- Product Type: Slotted Flat Head Machine Screw
- Drive Type: Slotted
- Head Type: Flat (Countersunk)
- Thread Type: Metric (MM), UNC, UNF, BSW, BSF
- Thread Direction: Right-hand (Left-hand available on request)
- Manufacturing Process: Cold Formed / Precision Machined
Standards
- DIN 963
- ISO 2009
- ANSI/ASME B18.6.3
- BS 4183
- Custom standards available upon request
Length / Size
- Diameter: M2 to M12
- Length: 5 mm to 100 mm
- Inch Sizes: #2 to 1/2"
- Custom sizes and thread lengths available on request
Material
- High-Quality Silicon Bronze Alloy (C65100, C65500, C65600 or equivalent grades)
Finish
- Natural Silicon Bronze Finish
- Polished Finish
- Custom finish available as per customer specifications
