Brass Square Bolt
Brass Square Bolts are durable threaded fasteners with a square head, designed for secure fastening in machinery, construction, marine, and industrial applications. Their square head provides a firm grip for easy tightening and loosening while offering excellent corrosion resistance and long service life.
For More Technical Details Click Here
Features
- Square head for improved wrench grip
- Excellent corrosion and rust resistance
- Precision-machined threads for secure fastening
- High strength and durability
- Non-magnetic and spark-resistant
- Easy installation and maintenance
- Available in standard and custom sizes
Specification
- Head Type: Square Head
- Thread Type: Metric (MM), UNC, UNF, BSW, BSF or custom
- Manufacturing Process: Cold Forged / CNC Machined
- Tolerance: As per international standards
- Custom dimensions available as per drawings and specifications
Applications
- Industrial machinery
- Construction and structural assemblies
- Marine and offshore equipment
- Electrical installations
- Automotive components
- Agricultural equipment
- General engineering and maintenance
Standards
- DIN 480
- ANSI / ASME B18.2.1 (Equivalent)
- ISO Standards (Equivalent)
- BS Standards
- Custom standards available on request
Length / Size
- Diameter: M5 to M24
- Length: 10 mm to 200 mm
- Custom lengths and thread sizes available
Material
- Free Cutting Brass IS 319 Type I
- CW614N / CW617N
- C36000
- CZ121 / CZ122
- Other brass grades available on request
Finish
- Natural Brass
- Nickel Plated
- Tin Plated
- Chrome Plated
- Zinc Plated
- Polished Brass
- Custom coatings and finishes available on request
